Katana 160 Artf A-BH022
No photo can do the model justice... it's huge!
Just like the Katana 60, the bigger 160 features lightweight laser cut balsa and ply components,
expertly jig built and hand covered in Oracover to a very high standard.
The large wing fairings give the Katana 160 a distinctive appearance, but it is the massive control surfaces that give the model its incredible performance.
Despite its size, the Katana 160 has great manoeuvrability and agility.
Designed for four channel R/C with 5 high torque servos and 1 standard.
Features:
. Factory built and covered - almost ready to fly
. All control surfaces pre-hinged
. Strong, lightweight factory painted fibreglass cowl and spats
. Aluminium tube wing joiner
Recommended EP Conversion
. Motor: KMS Quantum 5321/15
. ESC: KMS Optima 60HV
. Battery: 8S 4800mAh LiPo
Oracover & Balsa
If you are looking for a very fast and aerobatic plane, the Cobra is the right choice.
With it's swept -back wing leading edge and the anhedral stabilizer-elevator, it looks
and fli
• All Balsa and Plywood construction
• Covered with hand iron-on Oracover® Film
• Factory painted fiberglass cowling
• Pre-glued and pinned hinges on all control surfaces
• Detachable wing-halves secured with aluminum tubing
• All hardware and accessories included
Engine and radio control not included! es like a jet.
Engine and radio control not included!
Specifications
Wingspan: 1800mm
Length: 1670 mm
Weight: 5.35 kg
Engine Sizes: 2 stroke 108-160, 4 stroke 120-140, Gasser 30-35cc
Radio: min. 6ch.
Servos: min. 6
